High and Low Temperature (Humidity) Test Chamber is a professional environmental testing solution designed to simulate extreme temperature and humidity conditions for product reliability evaluation. The chamber accurately reproduces high temperature, low temperature, and constant temperature-humidity environments, helping manufacturers verify product performance, stability, and durability under different climatic conditions.
Equipped with a high-precision temperature and humidity control system, the Suzhoubaoshi ensures stable operation, fast response, and uniform environmental conditions inside the chamber. It supports programmable test cycles, automatic operation, and multiple safety protection functions, making it suitable for long-term continuous testing.
This environmental test chamber is widely used in electronics, electrical components, automotive parts, materials research, packaging, aerospace, and industrial manufacturing. With its reliable performance, durable structure, and flexible customization options, the JC-Series High and Low Temperature (Humidity) Test Chamber provides an ideal solution for quality control, product development, and compliance testing with international environmental standards.
| Model | BS-80G | BS150G | BS225G | BS-408G | BS-800G | BS-1000G | |
| Effective Volume | 80L | 150L | 225L | 408L | 800L | 1000L | |
| Internal Chamber Dimensions (W*H*D)(mm） | 400*500*400 | 500*600*500 | 600*750*500 | 800*850*600 | 1000*1000*800 | 1000*1000*1000 | |
| External Dimensions | 650*980*750 | 750*1080*850 | 850*1200*850 | 1050*1400*950 | 1250*1480*1150 | 1250*1480*1350 | |
| Weight(kg) | 180 | 200 | 240 | 280 | 300 | 380 | |
| Power | 220V 3KW | 220V 4KW | 220V 5KW | 380V 8KW | 380V 10KW | 380V 11KW | |
- Technical Parameters
| Item No. | Parameter Name | Technical parameters |
| 1.1 | Equipment Name | Button-Type High-Temperature Test Chamber |
| 1.2 | Equipment Introduction | This series of products is suitable for new energy, aerospace products, information electronic instruments and meters, materials, electrical engineering (products/components), automotive (products), metals, electronic products, various electronic components, and other fields. It is used to inspect their various performance indicators under high-temperature environments and for quality management purposes. |
| 1.3 | Equipment Model | BS-80G |
| 1.4 | Effective Volume | 80L |
| 1.5 | Internal Chamber Dimensions | 400*500*400 (W*H*D）（mm） |
| 1.6 | External Dimensions | 650*980*750(W*H*D) (mm) |
| 1.7 | Temperature Range | RT＋10℃→260℃ |
| 1.8 | Heating Rate |
RT＋10℃→260℃ ≥3℃/min
(Full-process Non-linearity & No-load Acceptance) |
| 1.9 | Temperature Display Accuracy | Temperature:0.1℃ |
| 1.10 | Temperature Deviation | Temperature:±2℃ |
| 1.11 | Temperature Fluctuation | Temperature:≤±0.5℃ |
| 1.12 | Temperature Uniformity | Temperature:≤2.5℃ |
| 1.13 | Weight | 180KG |
| 1.14 | Power | 220V/3KW |
| 1.15 | Others |
All the above performance indicators refer to the data measured under the conditions of no load, no test sample, and ambient temperature of 25±2℃.
Operating Noise:70dB (measured at 1 meter from the chamber door and 1.5 meters in height). |
| ), Self-Diagnosis Function |
