Product Description
Feature:
The programmable rapid temperature change testing machine is a macro-climate simulation environmental device, designed to evaluate the temperature-humidity aging resistance of electrical and electronic products. It is applicable for reliability testing of new energy components, automotive parts, household appliances, semiconductors, electronics, aerospace equipment, academic research materials, and instrument components under high-temperature, low-temperature, damp heat, and alternating damp heat conditions.
The programmable rapid temperature change testing machine is a macro-climate simulation environmental device, designed to evaluate the temperature-humidity aging resistance of electrical and electronic products. It is applicable for reliability testing of new energy components, automotive parts, household appliances, semiconductors, electronics, aerospace equipment, academic research materials, and instrument components under high-temperature, low-temperature, damp heat, and alternating damp heat conditions.
Test Standard:
General Standards
- GB/T 2423.2-2008 Test Method: High Temperature
- GB/T 2423.1-2008 Test Method: Low Temperature
- GJB150.4A-2009 Low Temperature Test Method
- GJB150.3A-2009 High Temperature Test Method
- Corrected Standard: GB/T 2423.4-2008/IEC 60068-2-30:2005 Test Db: Damp Heat, Cyclic (12h + 12h Cycle)
- GB/T 2424.6-2006 Environmental Testing for Electric and Electronic Products - Performance Qualification of Temperature-Humidity Test Chambers
- GB/T 10586-2006 Technical Conditions for Damp Heat Test Chambers
- GB/T 2424.5-2006 Environmental Testing for Electric and Electronic Products - Performance Qualification of Temperature Test Chambers
Acceptance Execution Standards
- Manufacturing Standards: In accordance with GB/T 10586-2006 Technical Conditions for Damp Heat Test Chambers and GB/T 10592-2008 High/Low Temperature Test Chambers.
- Calibration Standards: In accordance with GB/T 5170.2-2017 Environmental Testing Equipment for Electric and Electronic Products - Part 2: Calibration Methods for Temperature Test Equipment and GB/T 5170.5-2016 Environmental Testing Equipment for Electric and Electronic Products - Part 5: Calibration Methods for Damp Heat Test Equipment.
- Technical Standards: Acceptance based on the technical indicators specified in the signed contract.
| odel | BS-80AD | BS-150AD | BS-225AD | BS-408AD | BS-800AD | BS-1000AD | |
| Effective Volume | 80L | 150L | 225L | 408L | 800L | 1000L | |
| Internal Chamber Dimensions (W*H*D)(mm） | 400*500*400 | 500*600*500 | 600*750*500 | 800*850*600 | 1000*1000*800 | 1000*1000*1000 | |
| External Dimensions | Front-back Structure | 650*1380*1350 | 750*1380*1450 | 850*1480*1450 | 1050*1680*1550 | 1250*1850*1950 | 1250*1920*1950 |
| Lateral Structure | 950*1380*850 | 1050*1380*950 | 1150*1580*950 | 950*1680*1050 | 1550*1850*1450 | 1850*1900*1450 | |
| Weight(kg) | 250 | 280 | 320 | 350 | 380 | 400 | |
| Power | 220V 3KW | 380V 5.5KW | 380V 6KW | 380V 7.5KW | 380V 9.5KW | 380V 11.5KW | |
- Technical Parameters
| Item No. | Parameter Name | Technical parameters |
| 1.1 | Equipment Name | Programmable Constant Temperature and Humidity Chamber |
| 1.2 | Equipment Introduction | The Programmable Constant Temperature and Humidity Testing Machine, also known as the High-Low Temperature Alternating Damp Heat Testing Machine, falls under the category of large-scale climate simulation environmental equipment. It is suitable for conducting temperature and humidity aging tests on electrical and electronic products, including those used in new energy, automotive, household appliances, semiconductors, electronics, aerospace, universities and colleges, as well as instrumentation components. Specifically, it is applied to assess the adaptability of these products under environmental conditions such as high temperature, low temperature, damp heat, and alternating damp heat. |
| 1.3 | Equipment Model | BS-80AD |
| 1.4 | Effective Volume | 80L |
| 1.5 | Internal Chamber Dimensions | 400*500*400 (W*H*D）（mm） |
| 1.6 | External Dimensions |
Front-back Structure:650*1380*1350(W*H*D) (mm)
Lateral Structure:950*1380*850(W*H*D) (mm) （ Subject to the final confirmed 3D drawing ） |
| 1.7 | Temperature Range | -40℃~150℃ |
| 1.8 | humidity range |
20~98%R. H
(Temp. & Humidity Comparison Table) |
| 1.9 | Heating Rate |
-40℃ ~ 150℃ ≥3℃/min
(Full-process Non-linearity & No-load Acceptance) |
| 1.10 | Cooling Rate |
150℃ ~ -40℃ ≥1℃/min
(Full-process Non-linearity & No-load Acceptance) |
| 1.11 | Temperature and Humidity Display Accuracy |
Temperature:0.01℃
Humidity:0.1%R.H |
| 1.12 | Temperature and Humidity Deviation |
Temperature:±2℃
Humidity: When ≥75%RH, the humidity error shall be ≤+2 to -3%RH Humidity: When ＜75%RH, the humidity error shall be ≤+5%RH |
| 1.13 | Temperature and Humidity Fluctuation |
Temperature:≤±0.5℃
Humidity:+2/-3%R.H |
| 1.14 | Temperature and Humidity Uniformity |
Temperature:≤2℃
Humidity:+2/-3%R.H |
| 1.15 | Cooling Method | Air Cooling |
| 1.16 | Weight | 250KG |
| 1.17 | Power | 220V/3KW |
| 1.18 | Others |
All the above performance indicators refer to the data measured under the conditions of no load, no test sample, and ambient temperature of 25±2℃.
Operating Noise:70dB (measured at 1 meter from the chamber door and 1.5 meters in height). |
