BS-B-8000DD

The double-layer high and low temperature testing machine is a large-scale climate simulation environmental equipment. It is suitable for conducting temperature aging tests on electrical and electronic products
  • Single-layer Effective Volume: 2016L
  • Inner Chamber Dimensions: 14008001800 (WHD) (mm) (two chambers with independent control)
  • Outer Dimensions: Approximately 175022003550 (WHD) (mm)
    (Subject to the final confirmed 3D drawing)
  • Temperature Range: -40℃ ~ 150℃
  • Heating Rate: -40℃ ~ 100℃ approximately 1-3℃/min (non-linear throughout, no-load acceptance)
  • Cooling Rate: 100℃ ~ -40℃ approximately 0.7-1℃/min (non-linear throughout, no-load acceptance)
  • Load Capacity: Module weight ≥ 500KG, maximum heat generation: 2080W, capable of long-term operation at -40℃
  • Temperature Display Accuracy: 0.01℃
  • Temperature Deviation: ≤±2℃
  • Temperature Fluctuation: ≤±0.5℃
  • Temperature Uniformity: ≤2℃
  • Cooling Method: Water-cooled
  • Equipment Power: 380V, 50HZ, 45KW
